Introduction
The Blink Wired Floodlight Camera combines bright motion-activated lighting with 1080p HD security in one weatherproof package. Unlike battery-powered Blink cameras, this model requires hardwiring but delivers continuous power and enhanced night coverage. This guide covers installation, features, smart home integration, and troubleshooting for optimal performance.
Key Features of Blink Wired Floodlight Camera
✅ 2600-lumen LED floodlights (adjustable brightness)
✅ 1080p HD camera with infrared night vision
✅ Built-in siren (manual or motion-triggered)
✅ Two-way audio
✅ Works with Alexa (view on Echo Show/Fire TV)
✅ Weather-resistant (IP54 rating)
What’s in the Box?
- Blink Wired Floodlight Camera
- Mounting bracket & hardware
- Quick start guide
- Wire nuts & junction box adapter
Note: Requires existing electrical wiring (not plug-in).
Step-by-Step Installation Guide
1. Turn Off Power
- Locate your home’s circuit breaker and turn off power to the installation area.
- Use a voltage tester to confirm wires are de-energized.
2. Mount the Bracket
- Remove old floodlight (if applicable).
- Attach the Blink mounting bracket using included screws.
- Connect the black (live), white (neutral), and ground (green/bare) wires with wire nuts.
Pro Tip: Take a photo of your original wiring for reference.
3. Attach the Camera
- Align the camera with the bracket and twist to lock.
- Adjust the camera angle (110° field of view) and light direction.
4. Set Up in the Blink App
- Download the Blink Home Monitor app (iOS/Android).
- Tap “Add Device” → “Blink Wired Floodlight” and follow prompts.
- Connect to 2.4GHz Wi-Fi (5GHz not supported).
Optimizing Performance
1. Adjust Floodlight Settings
- Brightness: 25%-100% (lower saves energy).
- Motion-Activated: Enable in “Light Settings”.
- Duration: Set how long lights stay on (15 sec to 5 min).
2. Customize Motion Detection
- Sensitivity: High for driveways, low for busy streets.
- Activity Zones: Ignore trees or passing cars.
3. Enable Smart Alerts
- Person Detection: Reduce false alerts (requires Blink Subscription Plan).
- Siren Trigger: Sound automatically during events.
Troubleshooting Common Issues
1. Lights Won’t Turn On
- Check: Circuit breaker, wiring connections, and app settings.
- Test: Restore power and toggle settings in the Blink app.
2. Camera Offline
- Reset: Hold the pinhole reset button for 10 seconds.
- Wi-Fi: Ensure the Sync Module (if used) is within range.
3. False Motion Alerts
- Adjust sensitivity or create activity zones.
- Avoid pointing at moving branches or busy roads.
Blink Floodlight vs. Competitors
| Feature | Blink Wired Floodlight | Ring Floodlight Cam | Eufy Floodlight Cam |
|---|---|---|---|
| Resolution | 1080p | 1080p/1440p | 2K |
| Light Brightness | 2600 lumens | 2000 lumens | 2500 lumens |
| Power | Hardwired | Hardwired | Hardwired |
| Storage | Cloud (subscription) | Cloud/local (SD) | Local (built-in) |
| Price | $$ | $$$ | $$ |
Verdict: Blink offers budget-friendly floodlight security with Alexa compatibility.
FAQs About Blink Wired Floodlight Camera
Does it work without a subscription?
Yes, but you lose smart alerts and cloud storage.
Can I use it indoors?
Not recommended—it’s designed for outdoor weather resistance.
How long do lights stay on?
Adjustable from 15 seconds to 5 minutes after motion.
Does it record 24/7?
No—only motion-triggered clips (unless paired with a Sync Module 2).
Final Thoughts
The Blink Wired Floodlight Camera is ideal for lighting up dark yards while deterring intruders. For best results:
✔️ Install near entryways (garage, backyard).
✔️ Pair with Alexa for voice control.
✔️ Subscribe to Blink Plan for advanced features.
Need help? Contact Blink Support.
